CADDX 1303 6000KV Brushless Motors For Racing Drone Gofilm 20 1PCS For Gofilm 20 2inch FPV Drones DIY Parts CADDXFPV
28 orders (reference)
Description
Feature:
The CADDXFPV 1303 motor is a perfect candidate for a lightweight 2S to 4S setup. It can be built using regular one-piece injection molding to run 2-inch props on. And take it to the next level with our Gofilm 20 Brushless Whoop Quadcopter.
CADDXFPV T2-2-3 3-Blade Propellers 1.3mm Shaft will be the best match with CADDXFPV 1303 Brushless Motors, which forms a highly efficient power system, guaranteeing powerful flight capabilities and reduced noise levels.
Perfectly match with Super F405HD ELRS AIO, this motor will bring pilots a powerful flight experience.
Specifications
| Option | Values |
|---|---|
| High-concerned chemical |
|
| Is Electric |
|
| Quantity |
|
| Is it battery/power supply |
|
| Is it charger/adapter |
|
| Is Batteries Included |
|
| Size |
|
| Four-wheel Drive Attributes |
|
| Remote Control Peripherals/Devices |
|
| RC Parts & Accs |
|
| Material |
|
| Brand Name |
|
| Origin |
|
| Recommend Age |
|
| Use |
|
| Attribute | Value |
|---|---|
| High-concerned chemical | None |
| Is Electric | No Battery |
| Quantity | 1 pcs |
| Is it battery/power supply | N |
| Is it charger/adapter | N |
| Is Batteries Included | No |
| Size | 1303 |
| Four-wheel Drive Attributes | Motors |
| Remote Control Peripherals/Devices | Motor |
| RC Parts & Accs | Motors |
| Material | Metal |
| Brand Name | CADDXFPV |
| Origin | Mainland China |
| Recommend Age | 14+y |
| Use | Vehicles & Remote Control Toys |
Product Details
Feature:
The CADDXFPV 1303 motor is a perfect candidate for a lightweight 2S to 4S setup. It can be built using regular one-piece injection molding to run 2-inch props on. And take it to the next level with our Gofilm 20 Brushless Whoop Quadcopter.
CADDXFPV T2-2-3 3-Blade Propellers 1.3mm Shaft will be the best match with CADDXFPV 1303 Brushless Motors, which forms a highly efficient power system, guaranteeing powerful flight capabilities and reduced noise levels.
Perfectly match with Super F405HD ELRS AIO, this motor will bring pilots a powerful flight experience.
Specifications
Model 1303 6000KV Brushless Motors
KV 6000
Configu-ration 12N14P
Stator Diamter 13mm
stator Length 3.2mm
Shaft Diameter 1.5mm
Motor
Dimension(Dia.*Len) Ф 16.5*10.1mm
Weight(g) 5.6(5cm wire)
Idle current(5)@5V(A) 0.7
No.of Cells(Lipo) 2~4S
Max ContinuousPower(W)3s 250
internal Resistance 166mΩ
Max Current(3S) 16.9A
Max.Effciency Current (2-5A)>85%
