Foxeer ECHO 2 5.8GHz 9dBi Patch Antenna LHCP RHCP for RC Airplane FPV Racing Freestyle Drones VTX VRX Goggles Monitor DIY
From US $49.49 - 50.20
Est. US $49.49 - 50.20 / unit (1-9 pcs)
$46 @ 10+ pcs$43 @ 100+ pcs
Description
Packing list:
1pcs* Foxeer ECHO 2 5.8G 9dBi patch antenna
Variant
Selected priceUSD 50.27
Specifications
| Option | Values |
|---|---|
| Weight |
|
| Connector |
|
| Gain |
|
| Impedance |
|
Product Details
Specification:
Shell material: Imported PC+ABS
Weight: 8g
Antenna length: 21.7mm
Center frequency: 5.8 GHz
Gain : 8dBi
Radiation direction angle: 84.7 degree
Bandwidth: 500 MHz (5.5 – 6.0GHz)
Matching: VSWR < 1.25 (at center frequency)
Impedance: 50Ω
Axial ratio: < 3
Center frequency: 5600~5950MHz
Radiation efficiency: 98%
Polarization: RHCP/LHCP
Connector:SMA
Color: White/Red
Packing list:
1pcs* Foxeer ECHO 2 5.8G 9dBi patch antenna
Weight: 8g
Antenna length: 21.7mm
Center frequency: 5.8 GHz
Gain : 8dBi
Radiation direction angle: 84.7 degree
Bandwidth: 500 MHz (5.5 – 6.0GHz)
Matching: VSWR < 1.25 (at center frequency)
Impedance: 50Ω
Axial ratio: < 3
Center frequency: 5600~5950MHz
Radiation efficiency: 98%
Polarization: RHCP/LHCP
Connector:SMA
Color: White/Red
Packing list:
1pcs* Foxeer ECHO 2 5.8G 9dBi patch antenna
